掃描振鏡

美國CTI6230HB/C CTI6240H振鏡 劍橋6200系列振鏡代理維修

星之球科技 來源:http://laser1001.blog.sohu.com2011-07-19 我要評論(0 )

美國 CTI6230HB ,CTI6230HC系列掃描振鏡出售,CTI6240H振鏡,劍橋6200系列振鏡代理商,CTI振鏡維修159-901-990-65顧先生。CTI振鏡體積小,速度快,精度高,質量非常穩...

        美國CTI6230HB,CTI6230HC系列掃描振鏡出售,CTI6240H振鏡,劍橋6200系列振鏡代理商,CTI振鏡維修159-901-990-65顧先生。CTI振鏡體積小,速度快,精度高,質量非常穩定,被廣泛運用于激光打標,振鏡焊接,舞臺演示,水晶內雕,三維動態聚焦,醫療激光等領域。
        美國劍橋公司全名CambridgeTechnologyINC,簡稱CTI,成立于1978年作為一個供應商,在生物醫學研究領域的儀器儀表產品的開發商。當時他們建立技術創新,高品質的制造和客戶承諾CTI的標準。在努力實現的精度和準確度的最高級別的產品,劍橋高速奠定了閉環振技術,現在是劍橋的獨家產品重點的基礎。
劍橋科技公司成立,作為一個供應商,在生物醫學研究領域的儀器儀表產品的開發商。在1978年,當時我們建立技術創新,高品質的制造和客戶承諾我們的標準。在努力實現的最高水平準確度可以達到我們的產品,我們奠定了閉環振技術,現在是我們的獨家產品重點的基礎。
       通過我們不斷致力于研發和創新,我們已經開發了振鏡位置檢測器的設計和關鍵技術專利的進展。這些創新使我們能夠引進具有提高了精度,速度,性能和可靠性棒產品在科學和OEM光學掃描解決方案。我們的工程師與我們的客戶群開發產品的配置,易于使用和集成端無縫集成到他們的具體應用。我們的配套產品種類齊全,致力于客戶服務和持續的產品的研究方提供優質,創新,并相信我們的客戶期望從劍橋的技術保證。
       從第一劍橋科技提供的產品 - 所有的方式達到我們目前的產品線 - 。我們的承諾,這些已在我們的振技術的世界領先的標準,我們感到自豪,我們是保持建立在價值觀念 - 這些允許值使我們的客戶一次又一次的成功。
       2009年1月。市場和技術在光學掃描已加入為您帶來的光學掃描解決方案是最好的。從應用程序的特定組件掃描頭的領導人,我們的綜合公司為您提供無與倫比的掃描技術和最廣泛的模擬和數字組合掃描解決方案
Model 6231HC Moving Magnet Closed Loop Galvanometer Based Optical Scanner(CTI6231HC系列掃描振鏡)




The 6231H supports apertures of 8mm, 10mm, 12mm, and 15mm. It is shown here with the C connector and a 10mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degrees. Consult manual for complete operating instructions.

Mechanical
Rated Angular Excursion: 40°
Rotor Inertia: 0.82 gm cm2 , +/-10%
Torque Constant: 1.11x105 dyne cm/amp, +/-10%
Maximum Rotor Temperature: 110° C
Thermal Resistance (Rotor to Case): 1° C/Watt, Max

Electrical/Drive Mechanism
Coil Resistance: 1.27 Ohms, +/-10%
Coil Inductance: 176 µH, +/-10%
Back EMF Voltage: 195 µV/degree/sec, +/-10%
RMS Current: 5.8 Amperes at Tcase of 50° C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 250 µs, with balanced load of 0.3 gm*cm2

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/° C, Maximum
Zero Drift: 15 µrad/° C, Maximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%

Model 6230H Moving Magnet Closed Loop Galvanometer Based Optical Scanner(CTI6230H系列掃描振鏡)


The 6230H galvanometer can be designed and optimized for speed, size, cost and accuracy with typical beam diameters of 8mm, 10mm, 12mm, and 15mm. It is shown here with a 10mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degrees. Consult manual for complete operating instructions.

Mechanical Specifications
Rated Angular Excursion: 40°
Rotor Inertia: 0.97 gm cm2, +/-10%
Torque Constant: 1.31x105 dyne cm/amp, +/-10%

Maximum Rotor Temperature: 110°C Thermal
Resistance (Rotor to Case): 0.80°C/Watt, Max

Electrical Specifications/Drive Mechanism
Coil Resistance: 1.07 Ohms, +/-10%
Coil Inductance: 173 uH, +/-10%
Back EMF Voltage: 229 µV/degree/sec, +/-10%
RMS Current: 7.1 Amperes at Tcase of 50°C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 250 µs, with 8mm Y Mirror, settled to 99% 250 µs, with 10mm Y mirror, settled to 99%

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/°C, Maximum
Zero Drift: 15 µrad/°C, Maximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%

Model 6240H Moving Magnet Closed Loop Galvanometer Based Optical Scanner(CTI6240H系列掃描振鏡)


The 6240H galvanometer can be designed and optimized for speed, size, cost and accuracy with typical beam diameters of 12mm, 15mm, 20mm, 25mm, and 30mm. It is shown here with a 12mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degree. Consult manual for complete operating instructions.

Mechanical Specifications
Rated Angular Excursion: 40°
Rotor Inertia: 2.4 gm cm2, +/-10%
Torque Constant: 2.0x105 dyne cm/amp, +/-10%
Maximum Coil Temperature: 110°C
Thermal Resistance (Coil to Case): 0.62°C/Watt, Max

Electrical Specifications/Drive Mechanism
Coil Resistance: 1.03 Ohms, +/-10%
Coil Inductance: 350µH, +/-10%
Back EMF Voltage: 346 µV/degree/sec, +/-10%
RMS Current: 8.2 Amperes at Tcase of 50°C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 300 µs, with 12mm Y mirror, settled to 99%#p#分頁標題#e#
350µs, with 15mm Y mirror, settled to 99%
650 µs, with 20mm Y mirror, settled to 99%

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/°C, Maximum
Zero Drift: 15 µrad/°C, aximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%
本公司直接代理銷售美國劍橋(CambridgeTechnologyINC)的各型號掃描振鏡并提供維修服務
